Categories: IM CUBE ICE MAKERS,Ice Machine
FEATURES
SPECIFICATIONS
DOCUMENTATION
SUPPORT TOOLS
FEATURES
New intelligent control circuit dedicated to saving power and water consumption.
Microcomputer controller controls ice making process to work at peak performance in any conditions.
Inbuilt safety features – freeze cycle back up timer, defrost back up, low voltage and high amp protector.
New 7 segment operational display panel for ease of use.
Unique closed cell water circuit for ultimate contamination protection.
Durable stainless steel exterior.
Easily accessible and cleanable air filters reduce costly callouts.
Exceptionally hard crystal clear cubes that melt slowly.
Auto rinse and flush cycle.
3-year parts and labour warranty on entire unit, 5 year (parts only) on compressor and air-cooled condenser coil.
SPECIFICATIONS
Production Capacity per 24hours | Approx. 100kg @ 10°C Air temp; 10°C Water
Approx. 95kg @ 21°C Air temp; 15°C Water Approx. 82kg @ 32°C Air temp; 21°C Water |
Max Storage Capacity | Approx. 50kg ( Bin Control Setting Approx.28 kg) |
Freeze Cycle Time | Approx. 14 Min |
Ice Production Per cycle | Approx. 1.15kg/190pcs |
Width | 704mm |
Depth | 506mm |
Height | 1270mm (Includes 70mm-110mm Legs) |
Weight Net | 76kg |
Packed Weight | 85kg |
Cooling | Air |
AC Supply Voltage | 1 PHASE 220-240V 50Hz / 10 AMP Plug |
Amperage | Running: 4.5A Rated: 4.5A Starting: 19A |
Refrigerant Charge | Â R404A / 380g |
Operating Conditions | Ambient Temp.: 1-40°C Water Supply Temp.: 5-35°C Water Supply Pressure: 0.07-0.8MPa (0.7-8bar) Voltage Range: Rated Voltage ±6% |
Additional Parts | 87000105 High capacity Water Filter System 87000149 Water Filter System & Guage 81000116 Stainless Steel Hose 95001013 Adjustable Leg |
DOCUMENTATION
IM-130NE-21 CAD Drawing
Download
IM-130NE-21 Instruction Manual
Download
IM-130NE-21 Parts List
Download
IM-130NE-21 Spec Sheet
Download
