FEATURES
SPECIFICATIONS
DOCUMENTATION
SUPPORT TOOLS
FEATURES
New intelligent control circuit dedicated to saving power and water consumption.New 7 segment operational display panel for ease of use.Environmentally hard crystal clear cubes that melt slowly.Unique closed cell water circuit for ultimate contamination protection.Auto rinse and flush cycle.Micro computer controller controls ice making process to work at peak performance in any conditions.Easily accessible and cleanable air filters reduce costly callouts.Inbuilt safety features – freeze cycle back up timer, defrost back up, low voltage and high amp protector.Rated to 43°C ambient temperature (tropical conditions).Durable stainless steel exterior.3 year parts and labour warranty on entire unit, 5 year (parts only) on compressor and air cooled condenser coil.Achieved by stacking these units on top of each other.
SPECIFICATIONS
Production Capacity per 24hours | Approx. 220kg @10°C Air temp; 10°C Water
Approx. 205kg @21°C Air temp; 15°C Water Approx. 160kg @32°C Air temp; 21°C Water |
Max Storage Capacity | 91000027 Ice Storage Bin 91000053 Ice Storage Bin 91000054 Ice Storage Bin |
Freeze Cycle Time | Approx. 19 Min |
Ice Production Per cycle | Approx. 3.2kg/140pcs |
Width | 1084mm |
Depth | 700mm |
Height | 500mm |
Weight Net | 88kg |
Packed Weight | 101kg |
Cooling | Air |
AC Supply Voltage | 1 PHASE 220-240V 50Hz/ 10 AMP Plug |
Amperage | Running: 6.6A Rated: 6.6A Starting: 35A |
Refrigerant Charge | R404A / 480g |
Operating Conditions | Ambient Temp.: 1-40°CWater Supply Temp.: 5-35°CWater Supply Pressure: 0.07-0.8MPa (0.7-8bar) VoltageRange: Rated Voltage ±6% |
Additional Parts | 87000105 High capacity Water Filter System 87000149 Water Filter System & Guage 81000116 Stainless Steel Hose 95001013 Adjustable Leg 91000027 Ice Storage Bin 91000053 Ice Storage Bin 91000054 Ice Storage Bin 96000010 Top Kit |
DOCUMENTATION
IM-240DNE-28 CAD Drawing
Download
IM-240DNE-28 Instruction Manual
Download
IM-240DNE-28 Parts List
Download
IM-240DNE-28 Spec Sheet
Download
