FEATURES
Stainless steel interior and exterior.
4 x adjustable shelves with clips per door
Lockable split Doors
Programmable Digital controller and display.
2 years parts and labour warranty.
Comes standard with 4 x lockable castors.
Optional adjustable legs 150 -180mm (Sold separately).
Additional Shelves 590mm x 570mm & Clips (Sold separately)
SPECIFICATIONS
| Interior | Stainless Steel, |
| Exterior |
Stainless steel, Galvanized Steel
Powder Coated Rear/Bottom |
| Max Storage Capacity | 628L |
| Temperature Control |
Electronic Adjustable
Refrigerator: -18°C to -22°C |
| Evaporator | Fin & Tube type |
| Outside Dimensions Width |
700mm |
| Outside Dimensions Depth |
881mm |
| Outside Dimensions Height |
2,024mm
(Height Includes Castors) |
| Inside Dimensions Width |
596mm |
| Inside Dimensions Depth |
700mm |
| Inside Dimensions Height |
1,505mm |
| Weight Net | 113kg |
| Packed Weight | 136kg |
| Refrigeration System | Forced Air Circulation |
| AC Supply Voltage |
230V AC / 50 Hz / 10 Amp
|
| Refrigerant | R290/74g |
| Operating Conditions |
Ambient Temp.: 10-43°C
Voltage Range: Rated Voltage ±6% |
DOCUMENTATION
HF-77-2D SPLIT DOOR FREEZER DIMENSINAL DRAWING
Download
INSTRUCTION MANUAL
Download
HF-77-2D SPLIT DOOR FREEZER SPEC SHEET
Download
