Categories: Sushi Cabinets
FEATURES
SPECIFICATIONS
DOCUMENTATION
SUPPORT TOOLS
FEATURES
Airflow: The refrigeration-driven airflow from the evaporator is gentle and diffused, avoiding forced air circulation to prevent dehydration and weight loss, preserving the quality of displayed perishables.
Temperature Control: Flipping the tray upside down offers a simple solution for quick temperature control, reducing contact with the cold tray and enhancing exposure to the internal air, while an in-cabinet thermometer ensures constant temperature monitoring.
Attractive Display: The tubular-shaped evaporator consistently absorbs heat, freezing condensation externally to maintain an appealing frost layer without drips, complemented by adjustable LED lighting for versatile illumination.
Convenience: A practical anti-slip top provides a suitable surface for serving dishes, and the condensing unit’s placement on either side directs air outflow away from the operator.
Easy Cleaning: The sliding door’s height of 150 mm and the lightweight ABS trays with wave-shaped profiles enable effortless disassembly and removal for daily cleaning.
SPECIFICATIONS
Interior | Clear Glass, ABS Plastic, Stainless Steel |
Exterior | Clear Glass, ABS Plastic, PVC Plastic |
Effective Capacity | 72L |
Saturation Temperature | Approx 5 °C (Ambient temp 30°C, no load) |
Power Cord | 2.4m |
Outside Dimensions Width |
1800mm |
Outside Dimensions Depth |
345mm |
Outside Dimensions Height |
270mm |
Inside Dimensions Width |
1445mm |
Inside Dimensions Depth |
288mm |
Inside Dimensions Height |
157mm |
Weight Net | 42kg |
Packed Weight | 52kg |
Cooling | Air |
AC Supply Voltage | 1 PHASE 220-240V 50Hz/ 10Amp Plug |
Amperage | Rated: 1.0A Starting: 6A |
Refrigerant | R600a / 46g |
Operating Conditions | Ambient Temp.: 10 – 30°C Voltage Range: Rated Voltage ±6% |
DOCUMENTATION
HNC-180BE-R-BLH Dimensional Drawing
Download
HNC-180BE-R-BLH Instruction Manual
Download
HNC-180BE-R-BLH Parts List
Download
HNC-180BE-R-BLH Specifications
Download
