FEATURES
Stainless steel interior and exterior.
Top: Freezer – Bottom: Fridge
4 x adjustable shelves with clips.
Lockable Door
Programmable Digital controller and display.
2 years parts and labour warranty.
Comes standard with 4 x lockable castors.
Optional Adjustable legs 150 – 180mm (Sold separately).
Additional Shelves 580mm x 520mm & Runner (Sold separately)
Heated mullion
SPECIFICATIONS
| Interior | Stainless Steel, |
| Exterior | Stainless steel, Galvanized Steel Powder Coated Rear/Bottom |
| Max Storage Capacity | Fridge 285L Freezer 257L |
| Temperature Control | Electronic Adjustable Fridge 1°C to 4°C Freezer -16°C to -22°C |
| Evaporator | Fin & Tube type |
| Outside Dimensions Width |
700mm |
| Outside Dimensions Depth |
881mm |
| Outside Dimensions Height |
2,024mm
(Height Includes Castors) |
| Inside Dimensions Width |
Each Section 596mm |
| Inside Dimensions Depth |
Each Section 700mm |
| Inside Dimensions Height |
Each Section 692mm |
| Weight Net | 123kg |
| Packed Weight | 146kg |
| Refrigeration System | Forced Air Circulation |
| AC Supply Voltage | 230V AC / 50Hz / 10Amp |
| Refrigerant | R290 |
| Operating Conditions | Ambient Temp.: 10-43°C Voltage Range: Rated Voltage ±6% |
DOCUMENTATION
FRIDGE FREEZER HRF-77 COMBO 1D Dimensional Drawing
Download
FRIDGE FREEZER HRF-77 COMBO 1D Spec Sheet
Download
