FEATURES
Stainless steel interior and exterior.
4 x 2/1 GN adjustable shelves with S/S runners per door. (Total 8 Shelves)
Lockable Full-Length Door
Programmable Digital controller and display.
2 years parts and labour warranty.
Comes standard with 4 x lockable castors.
Optional Adjustable legs 150 – 180mm (Sold separately).
Additional Shelves 610mm x 540mm & runners (Sold separately)
SPECIFICATIONS
| Interior | Stainless Steel |
| Exterior | Stainless steel, Galvanized Steel Powder Coated Rear/Bottom |
| Max Storage Capacity | 1,365L |
| Temperature Control | Electronic Adjustable Refrigerator: 1°C to 4°C |
| Evaporator | Fin & Tube type |
| Outside Dimensions Width |
1,400mm |
| Outside Dimensions Depth |
881mm |
| Outside Dimensions Height |
2,024mm (Height Includes Castors) |
| Inside Dimensions Width |
1,296mm |
| Inside Dimensions Depth |
700mm |
| Inside Dimensions Height |
1,505mm |
| Weight Net | 184kg |
| Packed Weight | 231kg |
| Refrigeration System | Forced Air Circulation |
| AC Supply Voltage | 230V AC / 50 Hz / 10 Amp |
| Refrigerant | R290/105g |
| Operating Conditions | Ambient Temp.: 10-43°C Voltage Range: Rated Voltage ±6% |
DOCUMENTATION
0712744_A DIMENSIONAL LAYOUT HRWE147LS4-LDGN - HR-147-GN
Download
INSTRUCTIONS MANUAL
Download
SERVICE SPARE PART LIST
Download
HR-147-GN Fridge Upright Gastronorm Spec Sheet
Download
