FEATURES
Stainless steel interior and exterior.
4 x adjustable shelves with clips per door. (Total 8 Shelves)
Lockable split Doors
Programmable Digital controller and display.
2 years parts and labour warranty.
Comes standard with 4 x lockable castors.
Optional Adjustable legs 150 -180mm (Sold separately).
Additional Shelves 580mm x 520mm & clips (Sold separately)
SPECIFICATIONS
| Interior | Stainless Steel, |
| Exterior |
Stainless steel, Galvanized Steel
Powder Coated Rear/Bottom |
| Max Storage Capacity | 1,119L |
| Temperature Control |
Electronic Adjustable
Refrigerator: -18°C to -22°C |
| Evaporator | Fin & Tube type |
| Outside Dimensions Width |
1,200mm |
| Outside Dimensions Depth |
881mm |
| Outside Dimensions Height |
2,024mm
(Height Includes Castors) |
| Inside Dimensions Width |
1,076mm |
| Inside Dimensions Depth |
690mm |
| Inside Dimensions Height |
1,495mm |
| Weight Net | 164kg |
| Packed Weight | 204kg |
| Refrigeration System | Forced Air Circulation |
| AC Supply Voltage |
230V AC / 50 Hz / Single phase
|
| Refrigerant | R290/105g |
| Operating Conditions |
Ambient Temp.: 10-43°C
Voltage Range: Rated Voltage ±6% |
DOCUMENTATION
HF-127-4D SPLIT DOOR DIMENSINAL DRAWING
Download
INSTRUCTION MANUAL
Download
HF-127-4D SPLIT DOOR 2 Door Spec Sheet
Download
