FEATURES
SPECIFICATIONS
DOCUMENTATION
SUPPORT TOOLS
FEATURES
Stainless steel interior and exterior.
4 x adjustable shelves with clips per door
Lockable Full-Length Door
Programmable Digital controller and display.
2 years parts and labour warranty.
Comes standard with 4 x lockable castors.
Optional adjustable legs 150 – 180mm (Sold separately).
Additional Shelves 590mm x 570mm & Runner (Sold separately)
SPECIFICATIONS
Interior | Stainless Steel |
Exterior | Stainless steel, Galvanized Steel Powder Coated Rear/Bottom |
Max Storage Capacity | 628L |
Temperature Control | Electronic Adjustable Refrigerator: 1°C to 4°C |
Evaporator | Fin & Tube type |
Outside Dimensions Width |
700mm |
Outside Dimensions Depth |
881mm |
Outside Dimensions Height |
2,024mm (Height Includes Castors) |
Inside Dimensions Width |
596mm |
Inside Dimensions Depth |
700mm |
Inside Dimensions Height |
1,505mm |
Weight Net | 119kg |
Packed Weight | 142kg |
Refrigeration System | Forced Air Circulation |
AC Supply Voltage | 230V AC / 50 Hz / 10 Amp |
Refrigerant | R290/74g |
Operating Conditions | Ambient Temp.: 5-43°C Voltage Range: Rated Voltage ±6% |
DOCUMENTATION
0712736_A DIMENSIONAL LAYOUT HRWE77-LG - HR-77 GLASS DOOR
Download
INSTRUCTIONS MANUAL
Download
SERVICE SPARE PART LIST
Download
HR-77 Fridge Glass Door Spec Sheet
Download
