FEATURES
Sustainable & Efficient
Engineered for lower environmental impact and operating costs, featuring a variable-speed magnetic DC pump motor, eco-friendly R290 refrigerant, stand-by function, and premium foaming insulation. The improved water tank design and smart motor control further reduce water and energy consumption.
Durable & Hygienic Construction
A closed water circuit and closed cell system safeguard against contamination throughout the entire cubing process. Food-grade stainless steel (AISI 430) components, reduced-wear technology, and automated cleaning ensure long-lasting performance and high hygiene standards. Optional Scoop Holder-Kit available.
Advanced Technology
Intelligent water flow automatically adapts during each phase of ice production to prevent chipped or cloudy cubes. Cleaning notifications for the water circuit and condenser, along with an adjustable control panel for dimple size, provide enhanced precision and control.
Smart & Long-Lasting Design
High-grade insulation and optimized motor performance minimize mechanical stress while ensuring consistent, individual cube formation and reliable long-term operation.
Compact & Space-Saving
Efficient internal layout maximizes output within a compact footprint. The removable water tank and DC pump allow easy access for servicing without increasing space requirements.
Plug & Play Installation
User-friendly controls, dedicated stand-by and wash buttons, and easily removable components enable quick setup, simple operation, and hassle-free maintenance.
SPECIFICATIONS
| Exterior | Stainless steel AISI 441, Galvanized steel (Rear) |
| Production Capacity per 24hours | Approx. 38kg @10°C Air temp; 10°C Water Approx. 34kg @ 21°C Air temp; 15°C Water Approx. 26kg @ 32°C Air temp; 21°C Water |
| Max Storage Capacity | Approx. 15kg (Bin Control Setting Approx. 8kg) |
| Width | 633mm |
| Depth | 511mm |
| Height | 780mm |
| Weight Net | 44kg |
| Packed Weight | 54kg |
| Cooling | Air |
| AC Supply Voltage | 1 PHASE 220-240V 50Hz/ 10 AMP Plug |
| Amperage | Running: 1.6A Rated Motor: 1.6A Starting: 9A |
| Refrigerant Charge | R290 / 70g |
| Operating Conditions | Ambient Temp.: 1-40°C Water Supply Temp.: 5-35°C Water Supply Pressure: 0.07-0.8MPa (0.7 – 8bar) Voltage Range: Rated Voltage ±6% |
| Electric Consumption | 245W |
| Water Consumption Per 24h | Approx. 0.20m³ @10°C Air temp; 10°C Water Approx. 0.11m³ @ 21°C Air temp; 15°C Water Approx. 0.09m³ @ 32°C Air temp; 21°C Water |
| Electrical Circuit Breaker Protection | 5A |
| Heat Rejection (AT 32°C, WT 21°C) | 710W |
| Accessories Included | Installation kit, Legs, Scoop |
| Package Carton (W x D x H) | 735mm x 570mm x 864mm |
| GEM Number | AIM0019 |
