FEATURES
Sustainable & Efficient
Powered by an energy-efficient magnetic DC pump motor with variable speed, eco-friendly R290 natural refrigerant, and a stand-by function, the system reduces energy consumption while optimizing performance. Advanced foaming insulation and an improved water tank design further enhance energy and water savings.
Durable & Hygienic Construction
A closed water circuit and closed cell system ensure maximum hygiene and contamination protection. Food-grade stainless steel (AISI 430) components, reduced wear technology, and automated cleaning provide long-lasting durability and consistent food safety.
Advanced Technology
Smart water flow adjustment prevents chipped or cloudy ice, while the variable-speed DC pump motor ensures precision performance. Integrated cleaning alerts, condenser notifications, and an adjustable control panel enhance operational control and efficiency.
Smart & Long-Lasting Design
High-grade insulation, optimized motor control, and individual cube forming ensure consistent ice quality and extended component lifespan. Built-in maintenance reminders support reliable, long-term operation.
Compact & Space-Saving
Designed with an efficient internal layout, removable water tank and DC pump, and an optional Scoop Holder-Kit for organized storage—all without increasing footprint.
Plug & Play Installation
User-friendly controls, easy component access, and automated maintenance notifications allow for quick setup, simple operation, and hassle-free servicing.
SPECIFICATIONS
| Exterior | Stainless steel AISI 441, Galvanized steel (Rear) |
| Production Capacity per 24hours | Approx. 31kg @10°C Air temp; 10°C Water Approx. 28kg @ 21°C Air temp; 15°C Water Approx. 22kg @ 32°C Air temp; 21°C Water |
| Max Storage Capacity | Approx. 11.5kg (Bin Control Setting Approx. 6kg) |
| Width | 398mm |
| Depth | 451mm |
| Height | 787mm |
| Weight Net | 36kg |
| Packed Weight | 41kg |
| Cooling | Air |
| AC Supply Voltage | 1 PHASE 220-240V 50Hz/ 10 AMP Plug |
| Amperage | Running: 1.5A Rated Motor: 1.5A Starting: 8A |
| Refrigerant Charge | R290 / 65g |
| Operating Conditions | Ambient Temp.: 1-40°C Water Supply Temp.: 5-35°C Water Supply Pressure: 0.07-0.8MPa (0.7 – 8bar) Voltage Range: Rated Voltage ±6% |
| Electric Consumption | 215W |
| Water Consumption Per 24h | Approx. 0.15m³ @10°C Air temp; 10°C Water Approx. 0.07m³ @ 21°C Air temp; 15°C Water Approx. 0.05m³ @ 32°C Air temp; 21°C Water |
| Electrical Circuit Breaker Protection | 5A |
| Heat Rejection (AT 32°C, WT 21°C) | 570W |
| Accessories Included | Installation kit, Legs, Scoop |
| Package Carton (W x D x H) | 505mm x 575mm x 862mm |
| GEM Number | AIM0015 |
