Sustainable & Efficient
Eco-friendly R290 refrigerant and a variable-speed magnetic DC pump motor reduce energy consumption, while the stand-by function, premium foamed insulation, and improved water tank design minimise water usage and operating costs.
Durable & Hygienic Construction
Closed water circuit ensures maximum hygiene and food safety. Internal components are made from food-grade stainless steel (AISI 430), and an optional scoop holder kit promotes safe handling of ice.
Advanced Technology
Smart pump motor adjusts water flow throughout the ice-making process to prevent chipped or cloudy cubes. The closed cell system produces consistent, individual ice cubes.
Smart, Long-Lasting Design
Automated cleaning with wash auto-restart, plus water circuit and condenser cleaning notifications, simplify maintenance and extend equipment lifespan.
Compact & Space-Saving
Modular and stackable design allows efficient use of space while providing high ice output for growing operations.
Plug & Play Installation
Intuitive stand-by and wash controls, adjustable dimple size panel, and easily removable water tank and DC pump make installation and maintenance quick and simple.
| Exterior | Stainless steel (Side, Rear), ABS molding (Front, Top, Drain pan) |
| Production Capacity per 24hours | Approx. 250kg @10°C Air temp; 10°C Water Approx. 210kg @ 21°C Air temp; 15°C Water Approx. 175kg @ 32°C Air temp; 21°C Water |
| Corresponding Bins & Top Kits | B-301SA (No Top kit) | B-501SA (8D) | B-801SA (8D + 18D) | Double Stack- B- 801SA (4DM) |
| Width | 560mm |
| Depth | 700mm |
| Height | 780mm |
| Weight Net | 81kg |
| Packed Weight | 88kg |
| Cooling | Air |
| AC Supply Voltage | 1 PHASE 220-240V 50Hz/ 10 AMP Plug |
| Amperage | Running: 5.1A Rated Motor: 5.1A Starting: 20A |
| Refrigerant Charge | R290 / 90g |
| Operating Conditions | Ambient Temp.: 5-40°C Water Supply Temp.: 5-35°C Water Supply Pressure: 0.05-0.8MPa (0.5 – 8bar) Voltage Range: Rated Voltage ±6% |
| Electric Consumption | 960W |
| Water Consumption Per 24h | Approx. 0.250m³ @10°C Air temp; 10°C Water Approx. 0.210m³ @ 21°C Air temp; 15°C Water Approx. 0.175m³ @ 32°C Air temp; 21°C Water |
| Electrical Circuit Breaker Protection | 5A |
| Heat Rejection (AT 32°C, WT 21°C) | 1840W |
| Accessories Included | Installation kit, Scoop |
| Package Carton (W x D x H) | 665mm x 820mm x 950mm |
| GEM Number | AIM0036 |
