FEATURES
Sustainable & Efficient
Designed with sustainability in mind, the unit uses eco-friendly R290 natural refrigerant and a high-efficiency magnetic DC pump motor with variable speed to optimise performance while reducing energy consumption. A stand-by function and premium foamed insulation (instead of polystyrene) further enhance energy efficiency, while the improved water tank design and smart variable-speed pump reduce overall water usage.
Durable & Hygienic Construction
A fully enclosed water circuit ensures maximum hygiene and food safety throughout the entire ice-making process. Internal components are crafted from food-grade stainless steel (AISI 430) to minimise wear and tear, while automated cleaning functionality maintains long-term reliability. An optional scoop holder kit further supports hygienic handling.
Advanced Technology
Equipped with a variable-speed magnetic DC pump motor, the system intelligently adjusts water flow during different phases of ice production. This smart regulation prevents chipped or cloudy cubes and ensures consistently high ice quality. The closed cell system forms individual cubes for precision and clarity.
Smart, Long-Lasting Design
Automated cleaning cycles, along with water circuit and condenser cleaning notifications, help protect internal components and extend machine lifespan. High-grade insulation and robust engineering ensure dependable operation even in demanding commercial environments.
Compact & Space-Saving
An integrated internal drain pump allows installation up to 10 metres away and 1.5 metres above the drainage point, providing exceptional flexibility in compact or restricted spaces—ideal for busy kitchens and bar layouts.
Plug & Play Installation
Designed for convenience, the removable water tank and DC pump allow easy access for maintenance. The intuitive control panel enables simple adjustment of dimple size, making operation straightforward and user-friendly from day one.
SPECIFICATIONS
| Exterior | Stainless steel AISI 441, Galvanized steel (Rear) |
| Production Capacity per 24hours | Approx. 106kg @10°C Air temp; 10°C Water Approx. 96kg @ 21°C Air temp; 15°C Water Approx. 88kg @ 32°C Air temp; 21°C Water |
| Max Storage Capacity | Approx. 50kg (Bin Control Setting Approx. 28kg) |
| Width | 704mm |
| Depth | 506mm |
| Height | 1280mm |
| Weight Net | 72kg |
| Packed Weight | 84kg |
| Cooling | Air |
| AC Supply Voltage | 1 PHASE 220-240V 50Hz/ 10 AMP Plug |
| Amperage | Running: 4.2A Rated Motor: 4.2A Starting: 19A |
| Refrigerant Charge | R290 / 140g |
| Operating Conditions | Ambient Temp.: 1-40°C Water Supply Temp.: 5-35°C Water Supply Pressure: 0.07-0.8MPa (0.7 – 8bar) Voltage Range: Rated Voltage ±6% |
| Electric Consumption | 595W |
| Water Consumption Per 24h | Approx. 0.57m³ @10°C Air temp; 10°C Water Approx. 0.23m³ @ 21°C Air temp; 15°C Water Approx. 0.21m³ @ 32°C Air temp; 21°C Water |
| Electrical Circuit Breaker Protection | 5A |
| Heat Rejection (AT 32°C, WT 21°C) | 1450W |
| Accessories Included | Installation kit, Scoop |
| Package Carton (W x D x H) | 805mm x 580mm x 1375mm |
| GEM Number | AIM0006 |
