FEATURES
Sustainable & Efficient
Designed for environmentally responsible performance, the unit uses R290 natural refrigerant and a magnetic DC pump motor with variable speed to reduce energy and water consumption. High-grade foamed insulation and a stand-by function further enhance overall efficiency.
Durable & Hygienic Construction
A closed water circuit system protects against contamination throughout the entire ice-making process. Internal components made from food-grade stainless steel (AISI 430) reduce wear and extend service life. Automated cleaning and an optional scoop holder kit support superior hygiene and food safety.
Advanced Technology
The upgraded DC pump motor with smart water flow control adapts to each phase of the ice-making cycle, preventing chipped or cloudy cubes. The closed cell system with individual cube forming ensures consistently clear, high-quality ice.
Smart, Long-Lasting Design
Built for reliability, the machine features automated cleaning, water circuit and condenser cleaning notifications, durable insulation (foaming instead of polystyrene), and precision-engineered components for reduced wear and tear.
Compact & Space-Saving
A self-contained design with an optimised internal layout delivers high output within a compact footprint — ideal for professional environments where space is limited.
Plug & Play Installation
An intuitive control panel with adjustable dimple size, stand-by and wash functions, plus easily removable water tank and DC pump components, ensures simple installation, operation, and maintenance.
SPECIFICATIONS
| Exterior | Stainless steel AISI 441, Galvanized steel (Rear) |
| Production Capacity per 24hours | Approx. 106kg @10°C Air temp; 10°C Water Approx. 96kg @ 21°C Air temp; 15°C Water Approx. 88kg @ 32°C Air temp; 21°C Water |
| Max Storage Capacity | Approx. 50kg (Bin Control Setting Approx. 28kg) |
| Width | 704mm |
| Depth | 506mm |
| Height | 1280mm |
| Weight Net | 71kg |
| Packed Weight | 83kg |
| Cooling | Air |
| AC Supply Voltage | 1 PHASE 220-240V 50Hz/ 10 AMP Plug |
| Amperage | Running: 4.2A Rated Motor: 4.2A Starting: 19A |
| Refrigerant Charge | R290 / 140g |
| Operating Conditions | Ambient Temp.: 1-40°C Water Supply Temp.: 5-35°C Water Supply Pressure: 0.07-0.8MPa (0.7 – 8bar) Voltage Range: Rated Voltage ±6% |
| Electric Consumption | 595W |
| Water Consumption Per 24h | Approx. 0.57m³ @10°C Air temp; 10°C Water Approx. 0.23m³ @ 21°C Air temp; 15°C Water Approx. 0.21m³ @ 32°C Air temp; 21°C Water |
| Electrical Circuit Breaker Protection | 5A |
| Heat Rejection (AT 32°C, WT 21°C) | 1450W |
| Accessories Included | Installation kit, Scoop |
| Package Carton (W x D x H) | 805mm x 580mm x 1375mm |
| GEM Number | AIM0006 |
