FEATURES
Sustainable & Efficient
Built for reduced environmental impact and lower operating costs, featuring a variable-speed magnetic DC pump motor, eco-friendly R290 refrigerant, stand-by function, and high-grade foaming insulation. The improved water tank design and smart motor control also help minimize water and energy consumption.
Durable & Hygienic Construction
A fully closed water circuit and closed cell system ensure maximum protection against contamination. Food-grade stainless steel (AISI 430) components, reduced-wear technology, and automated cleaning deliver long-lasting durability and high hygiene standards. Optional Scoop Holder-Kit available.
Advanced Technology
Smart water flow automatically adjusts throughout the ice-making cycle to prevent chipped or cloudy cubes. Water circuit and condenser cleaning notifications, plus an adjustable control panel for dimple size, provide enhanced control and monitoring.
Smart & Long-Lasting Design
Premium insulation and optimized motor performance reduce mechanical stress while maintaining consistent, high-quality individual cube formation for dependable long-term operation.
Compact & Space-Saving
Efficient internal configuration maximizes production within a compact footprint. The removable water tank and DC pump allow easy access for servicing without requiring additional space.
Plug & Play Installation
User-friendly controls, dedicated stand-by and wash buttons, and easily removable components ensure straightforward installation, simple operation, and hassle-free maintenance.
SPECIFICATIONS
| Exterior | Stainless steel AISI 441, Galvanized steel (Rear) |
| Production Capacity per 24hours | Approx. 42kg @10°C Air temp; 10°C Water Approx. 38kg @ 21°C Air temp; 15°C Water Approx. 31kg @ 32°C Air temp; 21°C Water |
| Max Storage Capacity | Approx. 26kg (Bin Control Setting Approx. 18kg) |
| Width | 633mm |
| Depth | 506mm |
| Height | 950mm |
| Weight Net | 54kg |
| Packed Weight | 64kg |
| Cooling | Air |
| AC Supply Voltage | 1 PHASE 220-240V 50Hz/ 10 AMP Plug |
| Amperage | Running: 2.1A Rated Motor: 2.1A Starting: 11A |
| Refrigerant Charge | R290 / 110g |
| Operating Conditions | Ambient Temp.: 1-40°C Water Supply Temp.: 5-35°C Water Supply Pressure: 0.07-0.8MPa (0.7 – 8bar) Voltage Range: Rated Voltage ±6% |
| Electric Consumption | 290W |
| Water Consumption Per 24h | Approx. 0.30m³ @10°C Air temp; 10°C Water Approx. 0.08m³ @ 21°C Air temp; 15°C Water Approx. 0.07m³ @ 32°C Air temp; 21°C Water |
| Electrical Circuit Breaker Protection | 5A |
| Heat Rejection (AT 32°C, WT 21°C) | 830W |
| Accessories Included | Installation kit, Legs, Scoop |
| Package Carton (W x D x H) | 735mm x 570mm x 1012mm |
| GEM Number | AIM0008 |
