FEATURES
Sustainable & Efficient
Equipped with a variable-speed magnetic DC pump motor, eco-friendly R290 refrigerant, stand-by function, and premium foaming insulation for reduced energy consumption. The improved water tank design and smart motor control also help lower water usage.
Durable & Hygienic Construction
A fully closed water circuit and closed cell system protect against contamination throughout the ice-making process. Food-grade stainless steel (AISI 430) components, reduced-wear motor technology, and automated cleaning ensure long-term durability and high hygiene standards. Optional Scoop Holder-Kit available.
Advanced Technology
Intelligent water flow adapts to each phase of production to prevent chipped or cloudy ice. Cleaning notifications for the water circuit and condenser, along with an adjustable control panel for dimple size, provide enhanced monitoring and precision.
Smart & Long-Lasting Design
High-grade insulation and optimized motor performance reduce mechanical stress while maintaining consistent, high-quality individual cube formation for reliable long-term operation.
Compact & Space-Saving
Efficient internal design maximizes productivity within a compact footprint. The removable water tank and DC pump allow easy access without increasing space requirements.
Plug & Play Installation
User-friendly controls, dedicated stand-by and wash buttons, and easily removable components ensure straightforward setup, operation, and maintenance.
SPECIFICATIONS
| Exterior | Stainless steel AISI 441, Galvanized steel (Rear) |
| Production Capacity per 24hours | Approx. 42kg @10°C Air temp; 10°C Water Approx. 36kg @ 21°C Air temp; 15°C Water Approx. 29kg @ 32°C Air temp; 21°C Water |
| Max Storage Capacity | Approx. 15kg (Bin Control Setting Approx. 8kg) |
| Width | 633mm |
| Depth | 511mm |
| Height | 780mm |
| Weight Net | 44kg |
| Packed Weight | 54kg |
| Cooling | Air |
| AC Supply Voltage | 1 PHASE 220-240V 50Hz/ 10 AMP Plug |
| Amperage | Running: 1.6A Rated Motor: 1.6A Starting: 9A |
| Refrigerant Charge | R290 / 70g |
| Operating Conditions | Ambient Temp.: 1-40°C Water Supply Temp.: 5-35°C Water Supply Pressure: 0.07-0.8MPa (0.7 – 8bar) Voltage Range: Rated Voltage ±6% |
| Electric Consumption | 255W |
| Water Consumption Per 24h | Approx. 0.11m³ @10°C Air temp; 10°C Water Approx. 0.05m³ @ 21°C Air temp; 15°C Water Approx. 0.04m³ @ 32°C Air temp; 21°C Water |
| Electrical Circuit Breaker Protection | 5A |
| Heat Rejection (AT 32°C, WT 21°C) | 710W |
| Accessories Included | Installation kit, Legs, Scoop |
| Package Carton (W x D x H) | 735mm x 570mm x 864mm |
| GEM Number | AIM0018 |
