FEATURES
Sustainable & Efficient
A variable-speed magnetic DC pump motor optimises water flow during each stage of ice production, improving energy and water efficiency. The use of R290 natural refrigerant, a standby function, and high-grade foamed insulation further reduces environmental impact and operating costs.
Durable & Hygienic Construction
A closed water circuit protects the ice-making process from contamination, ensuring high hygiene standards. Internal components are made from food-grade stainless steel (AISI 430) for durability. An optional scoop holder kit supports safe and sanitary scoop storage.
Advanced Technology
The smart variable-speed pump motor adjusts water flow throughout the cycle to help prevent chipped or cloudy ice cubes. The closed cell system forms each cube individually, producing clear, consistent ice.
Smart & Long-Lasting Design
Features automated cleaning, water circuit and condenser cleaning notifications, and easily removable water tank and pump to simplify maintenance and extend machine life.
Compact & Space-Saving
The built-in drain pump allows flexible installation with drainage up to 10 m horizontally and 1.5 m vertically, making it ideal for tight kitchen or bar spaces.
Plug & Play Installation
A simple control panel allows easy adjustment of ice cube dimple size and convenient operation for quick setup and everyday use.
SPECIFICATIONS
| Exterior | Stainless steel AISI 441, Galvanized steel (Rear) |
| Production Capacity per 24hours | Approx. 38kg @10°C Air temp; 10°C Water Approx. 34kg @ 21°C Air temp; 15°C Water Approx. 26kg @ 32°C Air temp; 21°C Water |
| Max Storage Capacity | Approx. 15kg (Bin Control Setting Approx. 8kg) |
| Width | 633mm |
| Depth | 511mm |
| Height | 780mm |
| Weight Net | 45kg |
| Packed Weight | 55kg |
| Cooling | Air |
| AC Supply Voltage | 1 PHASE 220-240V 50Hz/ 10 AMP Plug |
| Amperage | Running: 1.6A Rated Motor: 1.6A Starting: 9A |
| Refrigerant Charge | R290 / 70g |
| Operating Conditions | Ambient Temp.: 1-40°C Water Supply Temp.: 5-35°C Water Supply Pressure: 0.07-0.8MPa (0.7 – 8bar) Voltage Range: Rated Voltage ±6% |
| Electric Consumption | 245W |
| Water Consumption Per 24h | Approx. 0.20m³ @10°C Air temp; 10°C Water Approx. 0.11m³ @ 21°C Air temp; 15°C Water Approx. 0.09m³ @ 32°C Air temp; 21°C Water |
| Electrical Circuit Breaker Protection | 5A |
| Heat Rejection (AT 32°C, WT 21°C) | 710W |
| Accessories Included | Installation kit, Legs, Scoop |
| Package Carton (W x D x H) | 735mm x 570mm x 864mm |
| GEM Number | AIM0019 |
