Sustainable Performance
The FM-120KE-HC uses natural refrigerant R290, an environmentally friendly choice that not only reduces environmental impact but also enhances overall performance and ice production efficiency.
Durable & Hygienic Construction
Built with a stainless steel exterior, the machine is designed for long-term durability. Its closed water circuit ensures hygiene by protecting the ice production process from contamination. Like all Hoshizaki machines, it is easy to operate, clean, and maintain.
Advanced Technology
The FM series features a worktime-based component replacement system, easily monitored via an intuitive control display to support preventive maintenance. Hoshizaki was also the first manufacturer to introduce an automated water circuit rinse cycle, helping prevent mineral buildup, protect the hydraulic system, and maintain exceptional sanitary conditions.
Smart, Long-Lasting Design
Engineered for reliability, the FM-120KE-HC incorporates carbon graphite bushings instead of traditional ball bearings, allowing grease-free operation. The absence of moving parts reduces wear and tear, while water-lubricated bearings help prevent calcification and bacterial contamination.
Compact & Space-Saving
With dimensions of 640 × 600 × 800 mm (W × D × H), this compact ice maker is ideal for installations where space is limited.
Plug & Play Installation
The convenient plug-and-play design allows for quick, straightforward installation, getting the machine up and running with minimal effort.
| Exterior | Stainless steel AISI 441, Galvanized steel (Rear) |
| Production Capacity per 24hours | Approx. 125kg @10°C Air temp; 10°C Water Approx. 105kg @ 21°C Air temp; 15°C Water Approx. 82kg @ 32°C Air temp; 21°C Water |
| Max Storage Capacity | Approx. 26kg (Bin Control Setting Approx. 21kg) |
| Width | 640mm |
| Depth | 600mm |
| Height | 800mm |
| Weight Net | 66kg |
| Packed Weight | 76kg |
| Cooling | Air |
| AC Supply Voltage | 1 PHASE 220-240V 50Hz/ 10 AMP Plug |
| Amperage | Running: 2.0A Starting: 8.8A |
| Refrigerant Charge | R290 / 100g |
| Operating Conditions | Ambient Temp.: 5-40°C Water Supply Temp.: 5-35°C Water Supply Pressure: 0.05-0.8MPa Voltage Range: Rated Voltage ±6% |
| Electric Consumption | 355W |
| Water Consumption Per 24h | Approx. 0.125m³ @10°C Air temp; 10°C Water Approx. 0.105m³ @ 21°C Air temp; 15°C Water Approx. 0.082m³ @ 32°C Air temp; 21°C Water |
| Electrical Circuit Breaker Protection | 6A |
| Heat Rejection (AT 32°C, WT 21°C) | 655W |
| Accessories Included | Installation kit, Scoop |
| Package Carton (W x D x H) | 746mm x 706mm x 887mm |
| GEM Number | AIM0023 |
